GlenGuard FR Hi-Vis

Safety in low-vis environments starts with the right vest, but true protection runs deeper than just a reflective surface. GlenGuard FR Hi-Vis combines ANSI-compliant visibility with inherent flame-resistant protection in a fabric built for all-day wear.

Protection that Goes Beyond Visibility

Your vest is your first line of defense. GlenGuard FR Hi-Vis makes sure it acts like one, delivering the highest standard of multi-hazard defense in a cooler, more comfortable fabric.
  • ANSI compliant for enhanced safety in low-vis conditions
  • Inherently flame-resistant for continuous protection
  • Built to withstand both flash fire and arc flash hazards
  • “No Melt, No Drip” fabric that won’t liquefy during heat exposure
  • Available in woven and mesh constructions for all-day compliance

Hi-Vis, Reimagined

Performance

Proven to protect against flash fire, arc flash exposure, and low visibility hazards

Comfort

Made with a lightweight, breathable material to combat heat stress and fatigue

Durability

Specially-engineered to withstand repeated wear in the toughest working conditions

Team Image

Versatile enough to support a consistent look across your entire team that won't rub off or wash out

Tested + Certified Protection

Our fabric is built to be resilient—just like the people who wear it. See how GlenGuard Hi-Vis measures up against potential hazards and performance standards.
Arc Flash (ASTM F1506, ASTM F1959, NFPA 70E)
  • ASTM F1506: The standard performance specification for flame-resistant and electric arc-rated protective clothing worn by workers potentially exposed to an electric arc flash and related thermal hazards.
  • ASTM F1959: The standard test method used to determine the arc rating (ATPV or EBT) of flame resistant textiles and fabric systems.
  • NFPA 70E: Establishes safe work practices to protect employees from electrical hazards by providing guidance on hazard risk assessments, energized work procedures and the selection of appropriate personal protective equipment (PPE).
Flash Fire (NFPA 2112)
NFPA 2112: Protects workers from flash fire exposure and related injury.
Low-Visibility (ANSI/ISEA 107)
Establishes performance specifications - including color and retroreflectivity - to ensure workers remain visible in low-visibility environments.
Electrostatic Decay (EN 1149)
  • EN 1149-3:Test method used to determine a material's ability to dissipate static electricity.
  • EN 1149-5: Protects workers against electrostatic hazards in combustible environments.
Trusted Compliance
TRUSTED COMPLIANCE
  • UL Listed: The gold standard for third party certified safety, performance and compliance.
  • Oeko-Tex Standard 100: An independent textile certification that verifies textile products and their components have been tested for harmful substances and meet stringent human-ecological requirements.

Fabric Styles + Specs

825: Woven CAT 1

825: Woven

Technical Sheet

Protection Level
CAT 1
Weight
6.2 oz/sq yd
Inherently FR for Life of Garment?
Yes
ANSI/ISEA 107-2015 Results
Pass
Arc Flash- NFPA 70E Results
5.5 cal/cm²
Construction
Plain Weave
Garment End Use
Vest
Colors Available
Fluorescent Yellow/Green
2400: Mesh CAT 1

2400: Mesh

Technical Sheet

Protection Level
CAT 1
Weight
6.0 oz/sq yd
Inherently FR for Life of Garment?
Yes
ANSI/ISEA 107-2015 Results
Pass
Arc Flash- NFPA 70E Results
4.9 cal/cm²
Construction
Mesh
Garment End Use
Vest
Colors Available
Fluorescent Yellow/Green
2500: Mesh CAT 1

2500: Mesh

Technical Sheet

Protection Level
CAT 1
Weight
6.0 oz/sq yd
Inherently FR for Life of Garment?
Yes
ANSI/ISEA 107-2015 Results
Pass
Arc Flash- NFPA 70E Results
4.7 cal/cm²
Construction
Mesh
Garment End Use
Vest
Colors Available
Fluorescent Yellow/Green
2825: Woven CAT 1

2825: Woven

Technical Sheet

Protection Level
CAT 1
Weight
6.0 oz/sq yd
Inherently FR for Life of Garment?
Yes
ANSI/ISEA 107-2015 Results
Pass
Arc Flash- NFPA 70E Results
7.3 cal/cm²
Construction
Plain Weave
Garment End Use
Vest
Colors Available
Fluorescent Yellow/Green
2950: Woven CAT 1

2950: Woven

Technical Sheet

Protection Level
CAT 1
Inherently FR?
Yes
ANSI compliant?
Yes
Arc rating
5.2
Construction
Mock Leno Woven
End Use
Vest
Colors
Fluorescent Yellow / Green

Experience the GlenGuard Advantage

Ready to think differently about your workwear? Contact a GlenGuard expert for more information.
